Rotary Tablet Press Machine ZP-9
Rotary Tablet Press Machine ZP-9
ZP-9 is a highly efficient electric rotary tablet press designed for the pharmaceutical and health care products industries, suitable for small-batch production and laboratory research and development. It adopts advanced rotary working principles and sophisticated control systems to ensure the consistency and high quality of each tablet. The machine can flexibly adjust the hardness and thickness of the tablets by adjusting parameters such as pressure and speed to meet the quality requirements of different products.
ZP-9 is equipped with a user-friendly HMI touch screen interface, supports multi-language selection, and provides an easy operation experience. It is designed and manufactured in strict accordance with the Good Manufacturing Practice (GMP) of pharmaceutical production to ensure sanitary conditions and safety; the modular structure design facilitates cleaning and replacement of parts, reducing downtime and maintenance costs. Not only is it suitable for small-batch production and laboratory research and development, it can also be used for teaching and training, and is an indispensable quality control tool in modern pharmaceutical production lines. Its compact design and multi-functional use make it an ideal choice for work environments with limited space, with a maximum production capacity of 36,000 tablets/hour.
The ZP-9 Rotary Tablet Press is a compact machine designed for small batch production. It is ideal for testing the compressibility of granular materials into tablets and is widely used in the pharmaceutical, chemical, food, and electronic industries.
Highlighted Features
- Small Batch Production: Perfect for evaluating the tablet-forming capability of granular raw materials.
- Versatile Tablet Shapes: Can press materials with powder content under 10% into round, special-shaped, and lettered tablets ranging from 4 to 12 mm in diameter.
- Wide Application: Suitable for pharmaceutical, chemical, food, and electronic manufacturing.
- Turntable Mechanism: Includes upper and lower bearing components, main spindle, and two turnplates with nine evenly distributed punch sets.
- Track Mechanism: Comprises upper and lower tracks and pressing wheels.
- Filling-Adjustment Unit: Adjusts the weight of the tablets.
- Tablet-Thickness Adjustment Unit: An external hand wheel rotates to adjust tablet thickness and hardness via the eccentric shaft.
- Feeding Mechanism: The fence-shaped feeder is mounted on the turntable.
- Peripheral Cover: Fully-sealed stainless steel design for easy cleaning and maintenance.
| Model | ZP-9 |
|---|---|
| Punch quantity | 9 Set |
| Max Output | 16,200 pcs/h |
| Max Tablet Pressure | 40 KN |
| Max Tablet Diameter | 12 mm |
| Max Tablet Thickness | 6 mm |
| Max Filling Depth | 15 mm |
| Turntable Working Diameter | 200 mm |
| Turntable Speed | 0-40 r/min |
| Middle Punch | Diameter 26mm Height 22mm |
| Lower Punch | Diameter 22mm Length 115mm |
| Max Filling Depth | 15 mm |
| Overall Dimensions | Length: 475mm Width: 465mm Height: 1,030mm Weight: 230kg |
