Digital Metal Separator SAYP-700S
Digital Metal Separator SAYP-700S
The Metal Detector T68 is an advanced pharmaceutical detector that integrates cutting-edge German technology to offer unparalleled precision, sensitivity, and stability in detecting and rejecting metal contaminants in tablets, capsules, and granules. This high-performance machine is equipped with an imported control system that can identify both magnetic and non-magnetic metal foreign bodies, including small metal chips and wires, ensuring thorough contaminant detection. Designed for efficiency, the T68 detects 100% of materials during operation, significantly reducing material loss and minimizing the risk of drug contamination.
User-friendly design is at the heart of the T68, featuring a microprocessor control system with automatic learning settings that simplify operation and maintenance. Moreover, the T68 complies with stringent HACCP, PDA, and GMP certification requirements, offering comprehensive certification documents and testing capabilities to ensure regulatory compliance. With its robust design, efficient contaminant detection, and ease of use, the Metal Detector T68 stands as an essential tool for pharmaceutical manufacturers committed to maintaining the highest standards of product safety and quality.
The Metal Separator SAYP-700S is designed for use in the pharmaceutical, health product, food, and chemical industries. It excels in detecting and separating metal impurities in products like tablets, capsules, and candies during processing.
Highlighted Features
- Wide Application: Ideal for tablets, capsules, and candies across multiple industries.
- High Detection Accuracy: Detects all magnetic and non-magnetic metal impurities, even if encapsulated, including steel, stainless steel, and aluminum.
- Advanced Design: Specially engineered to avoid interference from vibration and noise, ensuring precise detection.
- Ultra-High Frequency: Provides superior detection accuracy and performance for flakes, powders, fibers, and wet materials.
- Versatile Calibration Options: Available in various inlet sizes to accommodate different application needs.
- Robust Rejection System: Features a 316 stainless steel rejection device that is easy to disassemble and clean, meeting FDA and USDA standards.
- Efficient Inline Operation: Ensures uninterrupted production by removing impurities online, with easy manual adjustments for height and angle.
Model | SAYP700S-50 | SAYP700S-80 | SAYP700S-100 | SAYP700S-120 | SAYP700S-150 | SAYP700S-200 |
---|---|---|---|---|---|---|
Inlet Size | Φ50mm | Φ80mm | Φ100mm | Φ120mm | Φ150mm | Φ200mm |
Detection accuracy (empty machine) | Fe 0.4mm NOFe: 0.5mm SUS 0.7mm |
Fe 0.6mm NOFe: 0.8mm SUS 0.9mm |
Fe 0.8mm NOFe: 1.0mm SUS 1.2mm |
Fe 1.0mm NOFe: 1.2mm SUS 1.5mm |
Fe 1.2mm NOFe: 1.35mm SUS 1.6mm |
Fe 1.5mm NOFe: 1.7mm SUS 1.8mm |
Maximum production volume | 2000L/H | 8000L/H | 12000L/H | 16000L/H | 25000L/H | 44000L/H |
Working voltage | 220/110VAC(+10%,-15%) | 220/110VAC(+10%,-15%) | 220/110VAC(+10%,-15%) | 220/110VAC(+10%,-15%) | 220/110VAC(+10%,-15%) | 220/110VAC(+10%,-15%) |
Compressed air | 5-8bar | 5-8bar | 5-8bar | 5-8bar | 5-8bar | 5-8bar |
Net weight of equipment | about 35kg | about 39kg | about 50kg | about 55kg | about 70kg | about 75kg |
